Re: It lives

Post by RGV » Wed May 09, 2012 1:58 pm

Hey Greg, as long as the primary gear and alternator is OK ill take it, even then I can get others to replace them. Gearbox and clutch OK in it? The rest will be getting replaced with after market goodies.
That is depending on the price of course. If you coming to the lake in May/June and have room for it that would work out fine.

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
Greg Watters
Posts: 760
Joined: Mon Sep 27, 2004 8:57 pm

Re: It lives

Post by Greg Watters » Wed May 09, 2012 3:29 pm

As long as i don't forget in the packing rush i will bring it and you can have a look , no idea at all what the insides are like , but i cant see any reason why water would have gotten into the gearbox etc , previous owner left it out in the weather after removing the head and cyls

User avatar
BONES
Posts: 354
Joined: Wed Mar 15, 2006 4:28 pm
Location: Killara Sydney

Re: It lives

Post by BONES » Thu May 10, 2012 7:53 pm

Dave
RD will not work. All those cylinders and cranks are made for RZ/ banshee motors.
I am sure that r5/ds7, rd and lc are the same family and have a different bore spacing to an RZ.
Why not go to a 500cc engine? There is about a million different configerations up to 700cc for a twin (billet cases are advisable)
Have you seen these?
http://www.mattoonmachine.com/Billet_Cases.html
http://cpindinc.com/pub/view_product/15 ... 7258-115SA
The TZ is a 1980 piston port based on R5 cases-- lucky to make 70 hp on a good day-- the good days have all passed for mine.
The bore spacing for RD/LC/R5 is 102mm
Greg, what is the bore spacing on the 400?- it should be the same
cheers Bones

who
Posts: 3
Joined: Thu Mar 22, 2012 11:55 am

Re: It lives

Post by who » Tue May 15, 2012 7:30 pm

Did I hear some one mention RD400 basket case?...lol.

Greg, if you are looking to move it on to a good home please pm me. :)

Barrel/Bore spacing and hence crankshaft spacing on all of the horizontally split air cooled engines is the same. R5 through to the G RD 400's. I wouldn't be surprised if the RZ motors ran the same barrel spacing, the difference is the cylinder base stud orientation.

The development that is taking place on the RZ250-350 motors because of it's placement in a popular American non-power valved ATV is quite astounding. The new DM series are producing on the dyno, similar power and torque curves to the 1000 cc R1 (trinity racing 610cc Dm Cheetah)

Quite amazing for an engine and gearbox you can carry under one arm :shock:

User avatar
RGV
Posts: 678
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Wed May 16, 2012 3:07 am

Thanx for the links Bones, some nice HP made by them.

Im undecided which way I will go as yet but it will be a big bore and probably stroked Yamaha 2 smoker.

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
AuotonomousRX
Posts: 684
Joined: Wed Jan 06, 2010 10:05 pm
Location: Eyre Peninsula SA

Re: It lives

Post by AuotonomousRX » Wed May 16, 2012 10:15 am

I hope you can get that together, it would be a great thing.

A mate of mine is building a 485cc Yam powered Aprilia RS250 for the road.

It is a CPI kit based engine.
I understand that these kits have a long development history and work really well.

Pete
#866
Metric Target 250 on a 250 on a Red Bike

Pete :shock:
DLRA #866
SATA #49

User avatar
RGV
Posts: 678
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sat Feb 23, 2013 9:38 pm

Had a great 2013 Speed Week. Came home with a record. MPS/G 250 131 MPH

Thanx to all involved with the running of this years event and to my Pit Crew and wife Claire.


Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
internetscooter
Posts: 474
Joined: Mon Nov 20, 2006 12:18 pm
Location: Melbourne
Contact:

Re: It lives

Post by internetscooter » Sat Feb 23, 2013 9:55 pm

Good work Dave! I am going to have to change my class there is no way I can get tyres rated that fast ;)
Paul
---
DLRA #647
89.664 mph (aiming for 100mph+)
Vespa Labs [url]http://www.vespalabs.org[/url]

User avatar
RGV
Posts: 678
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sat Feb 23, 2013 10:04 pm

Thanx Paul. I over geared it for my run on Friday and it wouldnt pull redline but there is still quite a lot there for next year. It would rev to 12500 at the Test & Tune days but refused to go past 11200 in the top 2 gears on the salt. Ive got a year to sort that one out. EGT was 1250 F. and plugs looked good colour.
On my run on Tuesday I hit the 2 mile marker at 11000 in top and was doing 11200 at the 3 mile. That was the 131 MPH run. 11200 is all it would pull in 5th so I need to have a rethink on engine specs I think.

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
Cookey
Member
Posts: 443
Joined: Mon Oct 03, 2005 7:36 pm
Location: South Australia

Re: It lives

Post by Cookey » Sun Feb 24, 2013 9:01 am

Congratulations again Dave and many thanks to Claire who had (at times) to put up with my ranting in the timing van. :lol: :lol: :lol:
Lots of hard work will always pay off in the long run. :wink: :wink: :wink:
Cheers,
Tony Cooke
DLRA # 363

User avatar
RGV
Posts: 678
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sun Feb 24, 2013 9:52 am

Thanx Cookey. Claire says what happened the van stays in the van. :wink:

Dave

PS Claire said she had a great time in the timing van and is up for another stint next year. She has already started practising her cocktail mixing. I heard the Margaritas need work.

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
RGV
Posts: 678
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Thu Mar 07, 2013 7:47 pm

Ordered some new rods (stronger) for my Methanol Motor. Should be here within a week. Cant see me getting 150 MPH in the Gas class so Ross Brown has kindly volunteered to give me some tutoring in the ways of Methanol.
I have enough bits to build another motor so if it all turns to poo :shock: ill still have my old one for next year.

Should be LOUDER too. NICE :wink:

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
BONES
Posts: 354
Joined: Wed Mar 15, 2006 4:28 pm
Location: Killara Sydney

Re: It lives

Post by BONES » Thu Mar 07, 2013 9:06 pm

Keep an eye on Ross-- he has been known to tip the can

Bones

Stayt`ie
Posts: 958
Joined: Fri May 13, 2005 11:47 pm
Location: Mackay

Re: It lives

Post by Stayt`ie » Thu Mar 07, 2013 10:00 pm

an when he tips the can, check that ya needles dont melt, :wink: :lol: :lol: ,,,
First Australian to ride a motorcycle over 200mph at Bonneville,,,

User avatar
JonB
Posts: 268
Joined: Wed Oct 06, 2010 6:35 pm
Location: Brisbane

Re: It lives

Post by JonB » Fri Mar 08, 2013 7:04 am

He has his own special mix, a longneck to 5 liters ;)
