It lives

See cars and bikes being built for the salt

Moderator: DLRA

Post Reply
Michael Riddell
Posts: 3
Joined: Sun Jul 15, 2012 9:50 am

Re: It lives

Post by Michael Riddell » Fri Mar 08, 2013 8:58 pm

I was the other Nitro bike and it was "fill it to about half way then add two cups of nitro, shake well and serve". Didn't blow up!

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sat Mar 09, 2013 9:30 pm

Michael Riddell wrote:I was the other Nitro bike and it was "fill it to about half way then add two cups of nitro, shake well and serve". Didn't blow up!
1/2 way in a postie bike is ?? 2 cups. Big or small? You running very fat jetting or is this an educated guess? Glad to hear its still running. I havnt messed with Meth before so am on a steep learning curve.

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
gennyshovel
Posts: 834
Joined: Tue Mar 29, 2005 10:10 am
Location: Broken Hill

Re: It lives

Post by gennyshovel » Sun Mar 10, 2013 10:19 am

Michael Riddell wrote:I was the other Nitro bike and it was "fill it to about half way then add two cups of nitro, shake well and serve". Didn't blow up!
It's a pitty you didn't get an official "big" track time Michael
Tiny
Tiny DLRA# 484
Postiebike Racing , created & funded by TwoBob Engineering

Michael Riddell
Posts: 3
Joined: Sun Jul 15, 2012 9:50 am

Re: It lives

Post by Michael Riddell » Mon Mar 11, 2013 10:45 pm

The fuel mix wasn't quite hit and miss but Ross was involved. It worked out about right with 16%.The jetting was worked out and then we used what we had. Over geared it for some test runs so it wouldn't go bang. And the non-timing run was a bit disappointing but didn't want it to buggar up a bloody great week. There's always next year! (got to stop saying that)

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sat Mar 23, 2013 1:03 pm

Got my new rods, waiting for bearings and seals then its time to rebuild a crank for my new motor. New rods are 5mm longer so ive tracked down some pistons with a -3.5mm compression height, the rest of the height, 1.5mm, will be used to move the barrels up to create more of a top end port timing.



Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
AuotonomousRX
Posts: 690
Joined: Wed Jan 06, 2010 10:05 pm
Location: Eyre Peninsula SA

Re: It lives

Post by AuotonomousRX » Sun Mar 24, 2013 12:02 pm

Dave

They certainly are a more substantial Con Rod. 8)

Pete
Metric Target 250 on a 250 on a Red Bike

Pete :shock:
DLRA #866
SATA #49

User avatar
ChrisACT
Posts: 111
Joined: Thu Nov 10, 2011 7:39 pm

Re: It lives

Post by ChrisACT » Sun Mar 24, 2013 9:51 pm

Is the new rod heavier? Will you have to re-balance the crank?

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sun Mar 24, 2013 10:17 pm

Piston is 16g lighter and rod is about 14g heavier, so saving of 2g.

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sun Apr 14, 2013 9:57 am

Bit happening out in the shed over the w/end.

New piston and rod V old.


Some case flowing and port matching.


Next is building the crank and a dummy assemble of the motor to see what the 5mm longer rod is going to do to the port timing.
Ive found a piston with a 3.5mm lower compression height so only have to make up 1.5mm under the barrels.

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
AuotonomousRX
Posts: 690
Joined: Wed Jan 06, 2010 10:05 pm
Location: Eyre Peninsula SA

Re: It lives

Post by AuotonomousRX » Sun Apr 14, 2013 11:32 am

Nice work Dave :D

Pete
Metric Target 250 on a 250 on a Red Bike

Pete :shock:
DLRA #866
SATA #49

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sat Apr 20, 2013 8:26 pm

Got my carby's yesterday. Might have made a bit of a mistake when I ordered them. They turned out to be 40 mm not 38. Might be a touch too big.

Could probably get them to work but I wanted to keep the same size so I dont have to alter my air box, and I would have to make a pretty big bracket to hold these suckers on. Anyone want a pair of 40mm VM Mikunies?

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

internetscooter
Posts: 474
Joined: Mon Nov 20, 2006 12:18 pm
Location: Melbourne
Contact:

Re: It lives

Post by internetscooter » Sat Apr 20, 2013 11:33 pm

How do you calculate the size of the carb required? I have seen on an online calculator somewhere (can't remember now) where they spat out the size of the carb required for a given Hp. I based my single 38mm on what was standard and then added some. Is there a formula that you are using?
Paul
---
DLRA #647
89.664 mph (aiming for 100mph+)
Vespa Labs [url]http://www.vespalabs.org[/url]

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sun Apr 21, 2013 1:03 am

Hey Paul, Ive got a excel worksheet, "useful 2 stroke tuning sheet 3" Its got a fair bit of stuff on it. There are some GP bikes running 40+ carbs so I will have a look at how much messing round it will be to fit them. They are quite a bit bigger than the 38's im running.

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

internetscooter
Posts: 474
Joined: Mon Nov 20, 2006 12:18 pm
Location: Melbourne
Contact:

Re: It lives

Post by internetscooter » Sun Apr 21, 2013 9:38 am

RGV wrote:Hey Paul, Ive got a excel worksheet, "useful 2 stroke tuning sheet 3" Its got a fair bit of stuff on it. There are some GP bikes running 40+ carbs so I will have a look at how much messing round it will be to fit them. They are quite a bit bigger than the 38's im running.

Dave
Yes they look big ;) You might be able to make a couple of different manifold types to produce different characteristics - I might be interested but I'd only need one and only towards the end of the year (pending other mods).

Is that spreadsheet available online anywhere?
Paul
---
DLRA #647
89.664 mph (aiming for 100mph+)
Vespa Labs [url]http://www.vespalabs.org[/url]

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sun Apr 21, 2013 11:03 am

Not sure where I got it from, send me ya email and ill shoot a copy off to ya. Ive got a heap of different ones for all sorts of things. Head calculations, chamber design, n stuff.

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF
