It lives

See cars and bikes being built for the salt

Moderator: DLRA

Post Reply
User avatar
AuotonomousRX
Posts: 690
Joined: Wed Jan 06, 2010 10:05 pm
Location: Eyre Peninsula SA

Re: It lives

Post by AuotonomousRX » Tue Apr 23, 2013 5:18 pm

Dave

The Lectron people recommended 38mm Carbs for a full power RGV engine doing WOT Land Speed duty.

Pete
Metric Target 250 on a 250 on a Red Bike

Pete :shock:
DLRA #866
SATA #49

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Wed Apr 24, 2013 8:04 pm

Yep Pete thats what I thought. I bought the 40's thinking they were 38's. Im looking at some 38's on evil bay now. If I stuck with these id have to make new inlet manifolds and stuff as the carb body is bigger.

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Wed Jul 03, 2013 7:01 pm

Change of plans as far as Fuel goes. As im building a long rod crank for my bike im going to run on Gas again instead of going to Fuel or I wont know if ive gained anything from my crank or just the Methanol that has given me any performance gains. So ill hold off till I get this mod sorted.

OK bit been happening in the shed. Ive assembled the new long rod crank and assembled the top end to check the port timing. I didnt know what the extra 5mm on the rod was going to do. After a few different thickness base gaskets I got the deck height right and measured the timing. Worked out not too much, not too little, just right for the few more rev im looking for.



Piston top level with the bottom of the ports at BDC.



Then it was time to drill some lube holes in my nice new Wiseco pistons. Did a test drill in an old cast piston to see if it was going to work. Marked the exhaust bridge on the pistons and held my breath. I couldnt believe how much harder the forged Wiseco was compared to the cast Vortex I did the test drill on.



So my barrels can be packed up and sent over to UK for Ceramic Coating. Seems strange that I can send them to UK and have then state of the art Ceramic Coated for $300 less than sending them to Melbourne and having them Electrosil plated. Thats a free set of pistons.

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
BONES
Posts: 357
Joined: Wed Mar 15, 2006 4:28 pm
Location: Killara Sydney

Re: It lives

Post by BONES » Wed Jul 03, 2013 9:12 pm

I've heard mixed reports about the guys in Melbourne.
I'm taking a bag full of tz cylinders to the States with me-- about $200 a hole
Bones

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Wed Jul 03, 2013 10:17 pm

I got my last ones done by Electrosil in Melbourne, quick turnround but bloody expensive.

Im sending mine here this time. http://www.poetonaptec.co.uk/apticote.htm 135 Pounds each($227) + postage compared to $440 + postage here. Postage is only a bit over double to get them there. One of the guys with a big bore (Athina) and stroked RZ had all sorts of problems with it nipping up around the auxiliary exhaust ports. Many recoats with Nikasil till he tried this ceramic coating and he has 10,000 + km on it now with no problems. He pulled it down regularly for inspections and the bore looked to be like new last time he posted pics.

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
AuotonomousRX
Posts: 690
Joined: Wed Jan 06, 2010 10:05 pm
Location: Eyre Peninsula SA

Re: It lives

Post by AuotonomousRX » Wed Jul 03, 2013 10:43 pm

Looking good Dave.

It makes sense to stay in Gas and get a comparison.

I am going to send my Barrels over to UK as well.

Pete
Metric Target 250 on a 250 on a Red Bike

Pete :shock:
DLRA #866
SATA #49

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Thu Jul 04, 2013 12:09 am

Hey Pete, ya going for Nikasil or giving the Ceramic a go?

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
ROSS BROWN
Posts: 477
Joined: Thu Feb 18, 2010 6:43 pm
Location: COORPAROO BRISBANE

Re: It lives

Post by ROSS BROWN » Thu Jul 04, 2013 9:13 am

Switching to metanol half way through the week might not be to much of an issue Dave..
As long as your taps and feed lines will carry the volume.. set it up on the fat side and you should not
have an issue..
Ross..
IT IS ALL A RACE AGAINST TIME.
TIME WAITS FOR NO ONE.

HOW FAST CAN YOU GO ?

S/UF 925

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Thu Jul 04, 2013 9:39 pm

Hey Ross.
Keeping my options open on fuel. I hope to have my new engine finished for the SATA event. If not ill be fine tuning my old one, still some more to be had there im sure.

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
AuotonomousRX
Posts: 690
Joined: Wed Jan 06, 2010 10:05 pm
Location: Eyre Peninsula SA

Re: It lives

Post by AuotonomousRX » Fri Jul 05, 2013 1:37 pm

Ceramic Dave
Metric Target 250 on a 250 on a Red Bike

Pete :shock:
DLRA #866
SATA #49

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sat Sep 28, 2013 10:29 pm

Got my barrels back from the Ceramic Platers in the UK. Honing looks course but is quite smooth. Just needed to clean up the flashing in the ports a bit. Very nice reliving on the exhaust bridge. Overall a good job and cheaper than sending them to Melbourne for Nikasil. :roll:

Dave



Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
Greg Watters
Posts: 760
Joined: Mon Sep 27, 2004 8:57 pm

Re: It lives

Post by Greg Watters » Sun Sep 29, 2013 11:43 am

That similar to the DLC yamaha are using in the last 5 yrs or so ?

looks good

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Sun Sep 29, 2013 1:52 pm

Hey Greg, im not sure what coating DLC Yamaha use. This is the specs on the ceramic coating I got applied.

http://www.poetonaptec.co.uk/apticote.htm

Dave

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

User avatar
RGV
Posts: 688
Joined: Sun Feb 06, 2011 9:17 pm
Location: Adelaide Hills

Re: It lives

Post by RGV » Fri Oct 04, 2013 11:06 pm

Got this in the mail today.

And I got Cookys autograph. :lol:


Dave
Last edited by 1 on RGV, edited 0 times in total.

Last Minute Racing
DLRA #928

2010 MPS/G 250 118 MPH
2011 Washed Out
2012 Washed Out
2013 MPS/G 250 131 MPH (RECORD)
2014 MPS/G 250 140 MPH (RECORD)
2015 MPS/F 250 DNF
2016 MPS/F 250 114 MPH (RECORD)
2017 MPS/F 250 DNF

internetscooter
Posts: 474
Joined: Mon Nov 20, 2006 12:18 pm
Location: Melbourne
Contact:

Re: It lives

Post by internetscooter » Sat Oct 05, 2013 10:35 am

Nice, I want one - maybe there should be a 100mph club ;)
Paul
---
DLRA #647
89.664 mph (aiming for 100mph+)
Vespa Labs [url]http://www.vespalabs.org[/url]
